The equipment is to assemble the small backlight module automatically on the fixture tray according to the production process requirements. The assembly sequence is: manually place the outer frame of the backlight module on the mold - > Clear automatic cleaning (dust removal, electrostatic removal) - > Under diffuser - > Gloss 1 - > Gloss 2 - > Mask - > Press and automatically take out the finished product to the conveyor belt.

Equipment characteristics

* Japan Panasonic import control system, to ensure that the system is stable and reliable.

* Color touch screen LCD display input, Chinese menu, all parameter Settings browse simple and intuitive. !

* Yokogawa DD motor control, SMC motor components, smooth work, no vibration, to ensure position accuracy

* Using ionic air to eliminate static electricity, to ensure that the fit is flat, no stains, no wrinkles. There will be no bubbles, internal dirt, yarn, slag thorns bad *

* The use of separate production, easy to manage the customer workshop moving position, can enter the elevator, will not cause relocation difficulties.

*16 fixture bits, 8 of which produce the current product and 8 of which are presets for quick rotation. Make the change of production between different types of products convenient and fast, reduce the time of machine adjustment. Improve efficiency. For example: the model produced by class A has not been completed, and the staff of class B can use another mold, which will not cause multiple machine adjustments and waste unnecessary time

* covers an area of only 7 square meters, can completely replace manual production, reduce the defective rate, improve production efficiency, for the factory to save labor costs, management costs, plant costs.

Technical parameters:

* Main power supply specifications AC 220V±10%, 50Hz, 1000W

* Working pressure 0.4 -- 0.8Mpa

* Applicable products medium-sized: 5.7 inches

* Production efficiency 1200 pcs/H

* The number of loading platform stations can be put 16 fixtures; The fixture of A and B products is placed at intervals to facilitate rotation of production and save the time of adjusting the machine. !

* Appearance size (approx.) 2800mm(L)×2400mm(W)×2200mm(H)

* Body weight (approx.) 2000kg
